The Keysight 8762A/024 RF Switche is part of the Keysight range of RF signal routing instruments, built for RF signal routing in the field or laboratory. Highlights: 8762A/024 Coaxial Switch, DC.
- Keysight 8762A/024 Coaxial Switch, DC to
- 4 GHz, SPDT Product Overview The Keysight
- 8762A/024 is a high-performance coaxial switch designed for applications requiring fast switching speeds and low insertion loss
- It operates from DC to 4 GHz and features a single-pole, double-throw (SPDT) configuration
- The switch is ideal for use in test and measurement systems, signal routing, and antenna switching applications
- Features and Specifications Frequency range:
- DC to 4 GHz Insertion loss:
- 50 dB (typical) Switching speed:
- 10 ns Power handling:
- 200 W (CW) VSWR:
- 1.5:1 (typical) Operating temperature:
- 55°C to +85°C Dimensions:
- 2.25″ x 1.5″ x 0.75″ Benefits Low insertion loss and high isolation for accurate signal transmission
- Fast switching speed for rapid signal routing
- Wide frequency range for versatility in various applications
- Compact size for easy integration into test systems * Rugged construction for reliable operation in harsh environments
- Value to the Customer The Keysight 8762A/024
- Coaxial Switch provides customers with a high-quality, reliable solution for their signal switching needs
- Its low insertion loss, high isolation, and fast switching speed ensure accurate and efficient signal transmission
- The wide frequency range and compact size make it suitable for a variety of applications, while its rugged construction ensures long-term reliability
- By investing in the Keysight 8762A/024, customers can improve the performance and efficiency of their test and measurement systems
