Instek LCR-6100 High-Precision LCR Meter
The Instek LCR-6100 is a high-precision LCR meter designed for accurate and reliable measurement of inductance (L), capacitance (C), and resistance (R). With its wide frequency range of 10 Hz to 100 kHz and basic accuracy of 0.05%, this instrument delivers precise results for demanding applications in electronics manufacturing, research, and development. The LCR-6100 features a 5-digit LCD with backlight, auto-ranging, and auto-zero functions, ensuring ease of use and consistent performance.
Key Features & Highlights
- Wide Frequency Range: 10 Hz to 100 kHz for versatile testing across various components.
- High Accuracy: Basic accuracy of 0.05% ensures reliable measurements.
- High Resolution: 5-digit display with 0.0001 resolution for fine detail.
- Multiple Measurement Modes: L, C, R, Z, θ, D, Q, ESR, and more.
- Auto-Ranging and Auto-Zero: Simplifies operation and improves measurement stability.
- Large LCD Display: Clear, backlit screen for easy reading in various lighting conditions.
- USB and RS-232 Interfaces: Facilitate data transfer and remote control.
- Built-in Test Fixture: Provides convenient and stable measurements.
- Optional External Test Fixture: For testing larger components.
Applications
The Instek LCR-6100 is suitable for a wide range of applications, including component testing in production lines, quality control, incoming inspection, and laboratory research. It is ideal for measuring capacitors, inductors, resistors, and other passive components in fields such as electronics manufacturing, telecommunications, automotive, and education.
