Overview
The Megger TTRU1-BASIC is a compact handheld turns ratiometer test set for measuring transformer, motor, and inductive-component turns ratios. Its pass/fail indication and portable design support efficient testing in the field.
Applications and Selection
Choose this test set for portable turns-ratio checks where 37.5 VAC test voltage, 1 A test current, H/X leads, and user-defined pass/fail limits are appropriate. The rugged enclosure is intended for demanding testing environments.
Technical Information
- Measurement range: 0.001 to 9999.9
- Accuracy: 0.2% of reading ±2 digits
- Resolution: 0.001
- Test frequency: 50/60 Hz
- Display: 4-digit LCD
- Power: 4 AA batteries
- Dimensions: 190 x 100 x 50 mm; weight: 0.5 kg
- Includes H/X leads, user manual, and carrying case
Request a Quotation
Contact Indomultimeter for a quotation on the Megger TTRU1-BASIC and confirm your transformer testing requirements.
