Teledyne LeCroy ZD1500 Differential Probe, 1.5 GHz, 1 pF, 120 kOhm

Teledyne LeCroy ZD1500 Differential Probe

The Teledyne LeCroy ZD1500 is a high-performance active differential probe engineered for precision measurements in high-speed digital and analog applications. With a bandwidth of 1.5 GHz, an ultra-low input capacitance of 1 pF, and a high input impedance of 120 kOhm, this probe minimizes circuit loading and ensures signal fidelity. Whether you’re debugging high-speed serial buses, characterizing power electronics, or analyzing differential signals, the ZD1500 delivers reliable, accurate results.

Key Features & Highlights

• 1.5 GHz Bandwidth: Captures fast-rising edges and high-frequency components with ease.
• 1 pF Input Capacitance: Minimizes loading on the device under test, preserving signal integrity.
• 120 kOhm Input Impedance: Ensures minimal signal attenuation and accurate voltage measurements.
• 8 V Maximum Input Voltage: Suitable for a wide range of low-voltage applications.
• Differential and Single-Ended Measurements: Versatile for various test scenarios.
• Auto-Zero and Calibration: Simplifies setup and maintains measurement accuracy.
• Compact and Lightweight Design: Enhances portability and ease of use in lab environments.

Applications

The ZD1500 is ideal for engineers and technicians working on high-speed digital design, signal integrity analysis, power electronics, and embedded systems. Its high bandwidth and low loading make it perfect for probing DDR memory, PCIe, USB, and other high-speed interfaces. Additionally, its differential capability is essential for measuring floating signals and rejecting common-mode noise.
