The Teledyne LeCroy WAVESURFER 3104Z PROMO1 MSO Oscilloscope is a high-performance digital oscilloscope from the 3000z Series, designed to meet the rigorous demands of electronics, telecommunications, and research environments. With a 1 GHz bandwidth, 4 GS/s sample rate, and flexible 4/16 channel configuration, this instrument delivers exceptional signal visibility and analysis capabilities for engineers and technicians.
Key Features & Highlights
- 4/16 Channel Configuration: Supports up to 16 analog input channels or a mix of analog and digital channels, providing flexibility for complex system testing.
- 1 GHz Bandwidth: Captures high-frequency signals with clarity and accuracy, ideal for modern high-speed designs.
- 4 GS/s Sample Rate: Ensures high-resolution sampling for detailed waveform analysis and precise measurements.
- MSO Functionality: Integrates 16 digital channels for simultaneous analog and digital signal analysis, simplifying mixed-signal debugging.
- Large 12.1″ Touchscreen Display: Offers an intuitive user interface for efficient operation and waveform viewing.
- WaveScan™ Acquisition Technology: Provides fast waveform update rates and advanced triggering to accelerate troubleshooting.
- FFT and Mask Testing: Enables frequency domain analysis and automated pass/fail testing for quality assurance.
- Serial Bus Decoding: Supports popular protocols like I2C, SPI, and CAN for embedded systems debugging.
Applications
This oscilloscope is well-suited for power electronics design, embedded systems development, telecommunications testing, and general-purpose lab use. Its combination of high bandwidth, deep memory, and mixed-signal capabilities makes it a versatile tool for validating and debugging complex electronic systems.
