Teledyne LeCroy WAVESURFER 3054Z 500 MHz 4-Ch Digital Oscilloscope 4 GS/s

Teledyne LeCroy WAVESURFER 3054Z Digital Oscilloscope

The Teledyne LeCroy WAVESURFER 3054Z is a high-performance 4-channel digital oscilloscope engineered for demanding electronics, telecommunications, and research applications. With 500 MHz bandwidth, 4 GS/s sample rate, and 10 Mpts memory depth, it delivers precise signal capture and in-depth analysis capabilities.

Key Features & Highlights

• 4 Analog Input Channels – Simultaneously capture and compare multiple signals.
• 500 MHz Bandwidth – Accurately characterize high-frequency signals.
• 4 GS/s Sample Rate – Resolve fast transients and glitches with confidence.
• 10 Mpts Memory Depth – Record long time windows without sacrificing resolution.
• 12-bit Vertical Resolution – Enhanced detail for low-level signal measurement.
• 10.1-inch Capacitive Touchscreen – Intuitive operation with multi-touch gestures.
• Wave Inspector® Analysis Software – Advanced tools including FFT, histograms, and trend plots.
• Serial Bus Decoding – Debug and analyze I2C, SPI, UART, and more.
• Built-in Function Generator – Generate test signals without extra equipment.

Applications

The WAVESURFER 3054Z is ideal for power supply design, embedded system debugging, automotive electronics, and research laboratories. Its deep memory and advanced triggering help engineers capture elusive anomalies, while the intuitive interface accelerates time-to-insight.
