Teledyne LeCroy T3DSO2204A 4-Channel Digital Oscilloscope, 200 MHz, 2 GS/s

Teledyne LeCroy T3DSO2204A Digital Oscilloscope

The Teledyne LeCroy T3DSO2204A is a high-performance 4-channel digital oscilloscope designed for engineers and technicians who demand precision and reliability. With 200 MHz bandwidth, 2 GS/s sample rate, and 200 Mpts memory depth, this instrument delivers exceptional signal capture and analysis capabilities for a wide range of applications.

Key Features & Highlights

• 4 Analog Input Channels with 200 MHz bandwidth for simultaneous multi-signal analysis.
• 2 GS/s Real-Time Sample Rate ensures accurate capture of fast transients and high-frequency signals.
• 200 Mpts Memory Depth allows long-duration waveform capture with fine time resolution.
• 10.1-inch Capacitive Touchscreen with Wave Inspector® controls for intuitive navigation and zoom.
• Advanced Triggering including edge, pulse width, and video triggers to isolate specific events.
• Serial Bus Decoding for I2C, SPI, CAN, and RS-232/422/485 simplifies embedded system debugging.
• Built-in Function Generator provides signal generation for testing and validation.

Applications

The T3DSO2204A is ideal for electronic design, debugging, and analysis in R&D labs, educational institutions, and field service. It excels in power electronics, embedded systems, automotive electronics, and communication protocol analysis, making it a versatile tool for any engineering workspace.
