Keysight L7106B 20 GHz SP6T Multiport Coaxial Switch

Keysight L7106B 20 GHz SP6T Multiport Coaxial Switch

The Keysight L7106B (model L7106B/024/161) is a precision SP6T multiport coaxial switch engineered for applications up to 20 GHz. Part of Keysight’s L Series, this switch delivers exceptional RF performance with low insertion loss and high isolation, making it an ideal choice for test and measurement, signal routing, and antenna switching in both laboratory and production environments.

Key Features & Highlights

• Frequency Range: DC to 20 GHz, covering a wide spectrum for versatile RF testing.
• SP6T Configuration: Six ports provide flexible signal routing and switching capabilities.
• Low Insertion Loss: Typically less than 0.5 dB, ensuring minimal signal degradation.
• High Isolation: Typically greater than 60 dB, preventing signal leakage between ports.
• Compact Design: Measures just 2.5″ x 2.5″ x 0.5″, ideal for space-constrained setups.
• Ribbon Receptacle Connector: Offers a reliable and convenient connection method for rapid integration.
• Durable Construction: Built to withstand harsh environments, ensuring long-term reliability.

Typical Applications

• RF test and measurement systems
• Signal routing and switching matrices
• Antenna switching and diversity systems
• Automated test equipment (ATE)
• Communication systems requiring high-frequency switching

With its combination of high performance, compact size, and robust design, the Keysight L7106B is a dependable solution for engineers and technicians seeking precise signal switching up to 20 GHz.
