The Teledyne LeCroy CP150B Current Probe is a high-performance AC/DC current probe designed for use with oscilloscopes and other test equipment. With a 10 MHz bandwidth and a 150 A continuous measurement range (300 A peak pulse), it provides accurate current measurements for a wide range of applications, including power electronics, motor control, and automotive testing. The probe features a 2-meter cable and BNC connector for convenient connection to your oscilloscope.
Key Features & Highlights
- AC/DC current measurement with 10 MHz bandwidth
- 150 A continuous measurement range; 300 A peak pulse
- Accuracy: ±1% of reading ±0.5 A
- Sensitivity: 10 mV/A
- Input impedance: 1 MΩ; Output impedance: 100 Ω
- 2-meter cable length with BNC connector
- Overload protection for reliable operation
- Simple one-button operation for ease of use
- Rugged construction for industrial environments
Applications
The CP150B is ideal for engineers and technicians who need to measure current in power electronics, motor drives, automotive systems, and other industrial applications. Its high bandwidth and accuracy make it suitable for both design validation and troubleshooting.
