Keysight DSOX2014A 100 MHz 4-Channel Digital Oscilloscope

Keysight DSOX2014A Digital Oscilloscope

The Keysight DSOX2014A is a high-performance 4-channel digital oscilloscope from the 2000 X-Series, delivering 100 MHz bandwidth, 2 GS/s sample rate, and 1 Mpts memory depth. Designed for engineers and technicians, it provides precise signal visualization and advanced analysis tools to accelerate debugging and validation tasks.

Key Features & Highlights

• 4 Analog Channels: Simultaneously capture and compare multiple signals for comprehensive analysis.
• 100 MHz Bandwidth: Accurately measure a wide range of signals, from slow control signals to high-speed digital interfaces.
• 2 GS/s Sample Rate: Capture fast transients and high-frequency details with confidence.
• 1 Mpts Memory Depth: Record long time windows without sacrificing resolution, ideal for analyzing complex serial protocols.
• 8-bit Resolution: Clear signal display with fine detail for reliable measurements.
• Advanced Triggering: Trigger on specific signal conditions to isolate events of interest.
• Analysis Capabilities: Built-in waveform math, FFT, and mask testing for in-depth signal characterization.

Applications

This oscilloscope is well-suited for embedded system design, power electronics testing, automotive electronics, and education. Its combination of bandwidth, sample rate, and memory makes it a versatile tool for troubleshooting and validating electronic circuits.
