The Instek PSW-1080L445 is a programmable triple-channel switching DC power supply in the PSW-Multi Series. It provides 1,080 W total output with two 80 V channels and one 160 V channel for demanding test and development work.
Key specifications
- Three channels: 80 V/10 A, 80 V/10 A, and 160 V/5 A
- Total power output: 1,080 W
- Programmable switching frequency: 100 kHz
- Voltage and current regulation: 0.01% + 2 mV
- Ripple and noise: 1 mVrms
- Independent channel control
- Remote control through USB, RS-232, or GPIB interfaces
Recommended applications
Use it for automated test systems, electronics development, and applications requiring multiple regulated DC outputs. Confirm channel ratings and interface requirements before ordering.
