The Druck I1001 is a high-performance digital pressure gauge designed for demanding pressure measurement and calibration applications. With precision up to 0.005% FS and long-term stability of 0.01% Rdg per annum, this gauge delivers reliable and accurate readings in laboratory, industrial, and field environments. Its versatile design supports single or multiple pressure range configurations, making it adaptable to a wide spectrum of requirements.
Key Features & Highlights
- High accuracy up to 0.005% FS for precise measurements
- Pressure ranges up to 1000 bar (14500 psi / 100 MPa)
- Color touchscreen display with intuitive icon-driven menu
- Displays up to three pressures simultaneously in text or graphical format
- Data logging as standard, customizable over time periods
- Selectable graphical display and high-resolution touchscreen operation
- Barometric reference option and negative gauge calibration included
- Switch Test with Analogue output or Volt Free Contact options
- Connectivity: RS232, IEEE, Ethernet, and USB as standard
- 28 selectable pressure units plus 4 user-defined units
- Min/Max/Average display and leak test option
- Aeronautical option available for specialized applications
- Compatible with software packages for enhanced data analysis
Applications
The Druck I1001 is suitable for a variety of pressure testing and calibration tasks across industries such as aerospace, automotive, manufacturing, and process control. It is ideal for calibrating pressure sensors, transmitters, and gauges, as well as for leak testing and system validation. Its portability and robust feature set make it a valuable tool for both workshop and field use.
