Newport Electronics FMG73B Multifunction Data Logger is a compact flow-monitoring instrument for recording and indicating process flow. Its no-moving-parts design, NPN pulse output, and optional 4-20 mA signal support integration into monitoring systems.
Applications and selection
Select the FMG73B for liquid-flow monitoring in industrial, laboratory, and process applications where fast response, minimal straight-pipe requirements, and maintenance-free operation are useful. Confirm conductivity, flow range, process connection, and output model before ordering.
Technical information
- Flow range: 5 to 250 LPM (1.32 to 66 GPM)
- Accuracy: 1.5% of reading ±0.3% of range
- Repeatability: 1%
- Minimum conductivity: 50 µS/cm
- Maximum liquid temperature: 90°C (194°F)
- Maximum pressure: 16 bar (232 psi)
- Power supply: 24 VDC ±10%
- Protection: NEMA 4X (IP65), short-circuit and polarity protection
- Outputs: NPN square wave, 757 pulses/gal; 4-20 mA on -A models
- Connection: M12 x 1 plug; maximum load 250 ohm to ground
Request a quotation
Contact Indo Multimeter for a quotation on the Newport Electronics FMG73B Multifunction Data Logger. Include the flow medium, range, and required output. indomultimeter-seo-rewrite-v1
