Mensor CTD9100 Temperature Calibrator

The Mensor CTD9100 is a temperature calibrator with an operating range of -40 C to 650 C (Fahrenheit available), delivering 0.3 K accuracy at 100 C and 0.8 K at 650 C. Its 150 mm insertion depth and RS-485 interface make it suitable for calibrating a wide range of temperature sensors.

• Operating range: -40 C to 650 C (Fahrenheit available)
• Accuracy: 0.3 K at 100 C, 0.8 K at 650 C
• Stability: 0.05 K at 100 C
• Axial uniformity: 0.2 K at 100 C, 0.5 K at 650 C
• Display resolution: 0.01 C up to 100 C, then 0.1 C
• Test piece insertion length: 150 mm
• Interface: RS-485
• Power: AC 100-240 V, 50/60 Hz; power cord for USA/Canada, 115 VAC
• Includes calibration report 3.1
