Keysight MXR208B Infiniium 8-Channel 2 GHz 16 GS/s Real-Time Oscilloscope

Keysight MXR208B Infiniium Real-Time Oscilloscope

The Keysight MXR208B Infiniium Real-Time Oscilloscope is a high-performance 8-channel instrument engineered for demanding applications in electronics, telecommunications, and research. With 2 GHz bandwidth and 16 GS/s sample rate, it captures fast, complex signals with exceptional accuracy, making it a versatile tool for design validation, debug, and production test.

Key Features & Highlights

• 8 Analog Channels: Simultaneously view and analyze multiple signals for mixed-signal debugging and system-level characterization.
• 2 GHz Bandwidth: Capture high-frequency signals with minimal attenuation for accurate representation of fast edges and transients.
• 16 GS/s Sample Rate: Achieve fine time resolution to resolve glitches and anomalies in high-speed serial and parallel buses.
• 10-bit Vertical Resolution: See small signal details within large waveforms, improving measurement fidelity.
• 256 Mpts Memory Depth: Record long time windows at full sample rate for in-depth analysis of burst signals and rare events.
• 12.1-inch Capacitive Touchscreen: Navigate waveforms and settings intuitively with pinch, zoom, and drag gestures.
• Advanced Triggering & Analysis: Utilize a comprehensive set of triggers (edge, pulse, serial, etc.) and built-in measurement tools for time-domain, frequency-domain, and statistical analysis.
• Versatile Connectivity: Connect via USB, Ethernet, and GPIB for remote control, data transfer, and integration into automated test systems.

Applications

The MXR208B is ideal for engineers and researchers working on high-speed digital design, power integrity, embedded systems, and communications. Use it to debug complex electronic systems, characterize signal integrity, validate compliance, and accelerate time-to-market.
