Fluke 717-1500G Pressure Calibrator
The Fluke 717-1500G is a compact, rugged pressure calibrator designed for demanding industrial environments. It combines pressure generation and measurement in one handheld device, offering exceptional accuracy and stability for calibrating pressure gauges, transmitters, and switches. With a pressure range of -15 to 1500 psi, it covers a wide variety of applications in HVAC, process control, and maintenance.
Key Features & Highlights
- Pressure range: -15 to 1500 psi (0.5% full-scale accuracy)
- Built-in pressure pump for quick and easy pressure generation
- Simultaneous pressure and current (mA) measurement for calibrating P/I instruments
- Pressure switch test function captures set, reset, and deadband values
- Error% calculation for mA measurements enables fast pass/fail decisions
- Measure mA with 0.015% accuracy and 0.001 mA resolution
- Source 24V loop power for transmitter testing
- Compatible with 29 Fluke 700Pxx pressure modules to extend range up to 10,000 psi
- 1/8 NPT female pressure fitting, compatible with non-corrosive gases and liquids
- Select from eleven engineering units
- Zero, min, max, and hold functions
- EMI tolerant, dust and splash resistant
- Removable battery door for quick battery changes
- Long battery life with single 9V alkaline battery
- Holster with test lead storage and Toolpack magnetic hanging system
Applications
The Fluke 717-1500G is ideal for calibrating pressure gauges, transmitters, and switches in process industries, HVAC systems, and maintenance operations. Its rugged design and portability make it suitable for field use, while its precision ensures reliable results in laboratory settings.
