The AEMC 6522 is a versatile insulation tester designed for electrical professionals who demand reliable performance in the field. With selectable test voltages from 10 to 1000V and insulation resistance measurement up to 200GΩ, this compact and lightweight meter is ideal for testing cables, small motors, pumps, transformers, and industrial equipment. Its active voltmeter detects live voltage before testing, and automatic test inhibition ensures safety if voltage exceeds 25V.
Key Features & Highlights
- Selectable test voltages from 10 to 1000V (model dependent)
- Insulation resistance measurement up to 200GΩ (model dependent)
- Automatic discharge at completion of test
- Manual, Lock, and Timer test modes
- PI/DAR ratio calculations (model dependent)
- Active voltmeter detects live voltage prior to testing
- Automatic test inhibition if live voltage above 25V detected
- Programmable alarms with Pass/Fail indication (model dependent)
- 200mA/20mA continuity measurement with fuseless active protection
- Measures V (AC & DC), Hz, Ω, kΩ, capacitance, and cable length (model dependent)
- ΔRel mode for comparative measurements displayed as value or %
- Test lead compensation eliminates lead resistance from continuity measurements
- Data storage of test results (model dependent)
- Computer report generation via DataView® software (model dependent)
Applications
The AEMC 6522 is suitable for insulation testing on communication cables, Ethernet cables, and other low-voltage AC/DC wiring, as well as electronic components and circuits. It is also ideal for aerospace and defense applications where specific test voltages are required. Each unit includes a soft carrying pouch, two 1.5m test leads, two alligator clips, a black test probe, six AA batteries, a quick start guide, and a USB stick with DataView® software and user manual.
