The Additel ADT681-05-GP15K-PSI-B is a precision digital pressure calibrator designed for demanding industrial applications. With a wide measurement range of 0 to 15,000 psi and an accuracy of 0.05% of full scale, this instrument delivers reliable and repeatable pressure measurements for calibration, leak testing, and hydraulic testing. Its rugged construction and IP67 rating ensure durability in harsh environments, while the large backlit display and intuitive interface enhance usability.
Key Features & Highlights
- Pressure range: 0 to 15,000 psi (0 to 1000 bar)
- Accuracy: 0.05% of full scale
- IP67 rated: dust-tight and submersible in 1 meter of water
- Fully temperature compensated from -10°C to 50°C (14°F to 122°F)
- Up to eleven selectable pressure units
- Large 5-digit display with backlight and fan-shaped graph for % pressure indication
- Display flash warning when pressure exceeds 120% of full scale
- Data logging capability: up to 21,843 records with date, time, pressure, and temperature
- NIST traceable calibration certificate included
- Powered by 9V battery or optional AC adapter
- Bottom or panel mount options
Applications
The ADT681-05-GP15K-PSI-B is ideal for pressure calibration, leak testing, hydraulic testing, and general pressure measurement in industrial, laboratory, and field environments. Its high accuracy and robust design make it suitable for use in process control, manufacturing, and quality assurance.
