The Additel ADT681-02-CP300-PSI-B-DL is a precision digital pressure calibrator designed for demanding industrial environments. With a pressure range of 0 to 300 psi and an accuracy of 0.02% of full scale, this instrument delivers reliable and repeatable measurements for calibration, testing, and monitoring tasks. The large, backlit display with 5-digit resolution and a fan-shaped graph scale provides clear visual indication of pressure levels, while the rugged construction ensures durability in harsh conditions.
Key Features & Highlights
- Pressure range: 0 to 300 psi (20 bar)
- Accuracy: 0.02% of full scale
- Fully temperature compensated from -10°C to 50°C (14°F to 122°F)
- Large, easy-to-read display with 5-digit resolution and backlight
- Fan-shaped graph scale for visual pressure indication
- Data logging capability: stores up to 21,843 records (date, time, pressure, temperature)
- Up to eleven selectable pressure units
- Display flash warning when pressure exceeds 120% of FS
- NIST traceable calibration with data included
- Powered by 9V battery or optional AC adapter
- Bottom mount or panel mount options available
Applications
The ADT681-02-CP300-PSI-B-DL is suitable for a wide range of pressure measurement applications, including calibration of pressure transmitters, gauges, and switches; process monitoring in industrial plants; and long-term data logging for trend analysis. Its high accuracy and robust design make it an excellent choice for quality control, laboratory testing, and field service.
