Chart Recorders
Chart recorders produce a physical trace of a measurement against time, which some procedures and older quality systems still specify in preference to an electronic record.
MadgeTech, Dwyer Instruments, Monarch and Extech cover this range. Circular chart recorders suit a fixed rotation period such as 24 hours or seven days, while strip charts run continuously at a set speed. The practical considerations are consumables and drive: confirm chart paper and pen or stylus availability before committing, since a recorder whose charts are discontinued becomes scrap. Check the input types supported and whether battery operation is needed for portable survey work.
The Dwyer Instruments LCR20-111 is a handheld LCR meter offering ±0.1% basic accuracy for inductance, capacitance, and resistance measurements. With wide ranges (0.1 μH to 100 H, 0.1 pF to 100 mF, 0.1 Ω to 100 MΩ) and fast measurement speed, it’s ideal for field and lab use.
The MadgeTech PRTEMP1000-30-PSIA is a rugged pressure and temperature data logger with a 1/4″ NPT fitting, submersible up to 60 PSI. It measures pressure from 0 to 30 PSIA and temperature from -40 to 80°C, storing over 32,000 readings. Includes ISO17025 accredited calibration certificate.
The MadgeTech PRTEMP1000D-300 is a rugged, submersible differential pressure and temperature data logger with a 1/4″ NPT differential fitting. It measures pressure up to 300 PSID and temperature from -20 to 80°C with ±0.5°C accuracy, storing up to 32,766 readings. Ideal for industrial monitoring, it includes an ISO17025 accredited calibration certificate and is compatible with MadgeTech 4 Software.
The MadgeTech PRTRANS1000IS-1000-PSIA is an intrinsically safe transient pressure data logger with a 1/4″ NPT fitting, measuring 0 to 1000 PSIA. It features high-speed sampling, event-triggered recording, and includes an ISO17025 accredited calibration certificate.
The Monarch Instrument DC2-C-1-U6-1-0-0-0-0 chart recorder offers 2, 4, 6, or 12 direct universal inputs for DC voltage, current, and thermocouples. With high-speed storage up to 8 samples per second per channel, a 5.6-inch TFT touchscreen, and IP65 front panel, it’s ideal for industrial data logging.
The MadgeTech PRTEMP1000-100-PSIA is a rugged pressure and temperature chart recorder with a 1/4 NPT fitting, designed for industrial monitoring. It measures 0-100 PSIA and temperature from -40 to 80°C, storing up to 32,766 readings. Includes ISO17025 accredited calibration certificate.
The Extech RH520A Chart Recorder is a graphical data logger for humidity and temperature measurement, with dew point calculation. It features a large dual LCD, internal memory for 49,000 data points, and RS-232 PC connectivity for data analysis. Ideal for HVAC, cleanrooms, and industrial monitoring.
