The Additel ADT681-02-CP15-PSI-M-PB-DL is a precision digital pressure gauge from the 681 series, designed to deliver exceptional accuracy and reliability for industrial pressure measurement. With 0.02% full span accuracy and fully temperature compensated performance from -10°C to 50°C, this gauge ensures precise readings across a wide range of operating conditions. The ADT681-02 is equipped with a panel-mount configuration (PB) and data logging (DL) capability, making it a versatile choice for test benches, control panels, and calibration systems.
Key Features & Highlights
- 0.02% full span accuracy for critical measurements
- Pressure ranges up to 60,000 psi (4,200 bar) with various sensor options
- Fully temperature compensated from -10°C to 50°C
- Large, easy-to-read display with 5-digit resolution and backlight
- Fan-shaped graph scale for visual pressure indication
- Data logging of up to 21,843 records including date, time, pressure, and temperature
- Panel-mount design with back-mounted pressure port for easy installation
- NIST traceable calibration with data included
- 9V battery power or optional AC adapter
Applications
The ADT681-02 is ideal for use in calibration laboratories, industrial process control, hydraulic and pneumatic systems, and test and measurement applications where high accuracy and reliability are paramount. Its panel-mount configuration makes it suitable for permanent installation in control panels or test equipment, while the data logging feature enables long-term monitoring and analysis.
